Uwagi do pamięci RAM: Max. overclocking frequency:, - 1DPC 1R Max speed up to 8800+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max speed up to 5600+ MT/s, Supports Intel® POR Speed and JEDEC Speed, Supports Memory Overclocking and Intel® XMP 3.0, Supports Non-ECC, Un-buffered memory, Supports CUDIMM
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 3x M.2 - RAID 0, 1, 5
Uwagi do kontrolera SATA: - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, supports 2280/2260/2242 devices, - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,, supports 2280/2260/2242 devices, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,, supports 2280/2260/2242 devices
Uwagi do karty graficznej: Support HDMI™ 2.1, maximum resolution of 4K 60Hz, Support DisplayPort 1.4, maximum resolution of 4K 60Hz, Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over, USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz, Graphics specifications may vary depending on the CPU installed
Uwagi do złącz PCI: - PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset), - PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek® RTL8125D)
Maksymalna ilość portów USB 2.0: 4
Maksymalna ilość portów USB 3.x: 10
Maksymalna ilość portów USB 4.0: 1
Porty USB na panelu tylnym: 6x USB 3.0 + 1x USB 3.2 Type-C + 1x Thunderbolt 4/USB4 Type-C
Gniazda USB na płycie głównej: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.2 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Intel® Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, 6GHz band support may depend on every country's regulations and Wi-Fi 7, will be ready in Windows 11 version 24H2., The Bluetooth version may be updated, please refer to the Wi-Fi chipset, vendor's website for details. Bluetooth 5.4 will be ready in, Windows 11 version 24H2.
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: Thunderbolt 5 card connector(JTBT5, support RTD3), CPU Fan, Combo Fan (Pump_Sys Fan), 4x System Fan, EZ Conn-header (JAF_1), 2x Front Panel, Chassis Intrusion (JCI), Front Audio, Tuning Controller Connector, 3x Addressable V2 RGB LED connector, RGB LED connector, Gniazdo modułu TPM
Wyposażenie dodatkowe: Quick Installation Guide, European Union Regulatory Notice, 2x SATA Cables, 3x EZ M.2 Clips II, EZ M.2 Clip II Remover, EZ Wi-Fi Antenna, 1 to 2 EZ Conn-Cable (V1)
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows® 11 64-bit
2x Front Panel, 3x Addressable V2 RGB LED connector, 4x System Fan, Chassis Intrusion (JCI), Combo Fan (Pump_Sys Fan), CPU Fan, EZ Conn-header (JAF_1), Front Audio, Gniazdo modułu TPM, RGB LED connector, Thunderbolt 5 card connector(JTBT5, support RTD3), Tuning Controller Connector
Maksymalna ilość portów USB 2.0:
4
Maksymalna ilość portów USB 3.x:
10
Maksymalna ilość portów USB 4.0:
1
Maksymalna wielkość pamięci:
256 GB
Obsługiwane typy procesorów:
Intel Core Ultra Processors (series 2)
Opakowanie:
BOX
Port Bluetooth:
Bluetooth V5.4
Port LAN:
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek® RTL8125D)
Port PS/2:
Brak
Port równoległy (LPT):
Brak
Port szeregowy (COM):
Brak
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax/be
Porty USB na panelu tylnym:
6x USB 3.0 + 1x USB 3.2 Type-C + 1x Thunderbolt 4/USB4 Type-C
Graphics specifications may vary depending on the CPU installed, Support DisplayPort 1.4, maximum resolution of 4K 60Hz, Support HDMI™ 2.1, maximum resolution of 4K 60Hz, Thunderbolt™ 4 ports, supporting DisplayPort 2.1 with UHBR20 over, USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz
Uwagi do kontrolera SATA:
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, - M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 ,, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode,, supports 2280/2260/2242 devices
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 8800+ MT/s, - 1DPC 2R Max speed up to 7200+ MT/s, - 2DPC 1R Max speed up to 6400+ MT/s, - 2DPC 2R Max speed up to 5600+ MT/s, Max. overclocking frequency, Supports CUDIMM, Supports Intel POR Speed and JEDEC Speed, Supports Memory Overclocking and Intel XMP 3.0, Supports non-ECC, un-buffered memory
Uwagi do WiFi / BT:
6GHz band support may depend on every country's regulations and Wi-Fi 7 (11978), Intel® Wi-Fi 7, Supports 802.11 a/ b/ g/ n/ ac/ ax/ be, Supports Bluetooth® 5.4**, MLO, 4KQAM, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, The Wireless module is pre-installed in the M.2 (Key-E) slot, vendor's website for details. Bluetooth 5.4 will be ready in (1667), will be ready in Windows 11 version 24H2., Windows 11 version 24H2.
Uwagi do złącz PCI:
- PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), - PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset), - PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU)
Wymiary [S x W] (mm):
243,84 x 304,8
Wyposażenie dodatkowe:
1 to 2 EZ Conn-Cable (V1), 2x SATA Cables, 3x EZ M.2 Clips II, European Union Regulatory Notice, EZ M.2 Clip II Remover, EZ Wi-Fi antenna, Quick Installation Guide
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek ALC897
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 3x M.2 - RAID 0, 1, 5
Złącza PCI Express x16:
4
