Uwagi do pamięci RAM: Max. overclocking frequency:, - 1DPC 1R Max speed up to 7800+ MHz, - 1DPC 2R Max speed up to 6400+ MHz, - 2DPC 1R Max speed up to 6400+ MHz, - 2DPC 2R Max speed up to 5400+ MHz, Supports non-ECC, un-buffered memory, Supports AMD EXPO
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 4x M.2 - RAID 0, 1
Uwagi do kontrolera SATA: M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280, devices, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, devices, M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260, devices, M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260, devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: Support HDMI 2.1, maximum resolution of 4K 60Hz, Support DP 1.4, maximum resolution of 4K 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed
Zintegrowana karta dźwiękowa: Realtek® ALC897 7.1-Channel High Definition Audio
Uwagi do złącz PCI: Supports x16/x1/x4, PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek® RTL8125BG)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 13
Porty USB na panelu tylnym: 4x USB 2.0 + 4x USB 3.0 + 3x USB 3.1 + 1x USB 3.2 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.1 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: AMD Wi-Fi 6E, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* band, Wi-Fi 6E 6GHz may depend on every country's regulations and will be ready, in Windows 11, Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, Pump Fan, 6x System Fan, 2x Front Panel, Złącze czujnika otwarcia obudowy, TBT connector, Tuning Controller Connector, 2x Addressable V2 RGB LED connector, 2x RGB LED connector, Gniazdo modułu TPM, 4x EZ Debug LED, 2x Antenna Ports, Przycisk BIOS FlashBack na panelu tylnym
Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed, Support DP 1.4, maximum resolution of 4K 60Hz, Support HDMI™ 2.1, maximum resolution of 4K 60Hz
Uwagi do kontrolera SATA:
devices, M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280, M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260, M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260, M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 7800+ MHz, - 1DPC 2R Max speed up to 6400+ MHz, - 2DPC 1R Max speed up to 6400+ MHz, - 2DPC 2R Max speed up to 5400+ MHz, Max. overclocking frequency, Supports AMD EXPO, Supports non-ECC, un-buffered memory
Uwagi do procesora:
Supports AMD Ryzen™ 8000/ 7000 Series Desktop Processors
Uwagi do WiFi / BT:
AMD Wi-Fi 6E, Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11, in Windows 11, Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* band, The Wireless module is pre-installed in the M.2 (Key-E) slot, Wi-Fi 6E 6GHz may depend on every country's regulations and will be ready (5374)
Uwagi do złącz PCI:
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset), PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset), Supports x16/x1/x4
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
243,84 x 304,8
Wyposażenie dodatkowe:
2x SATA Cable, 3x M.2 Clips, Cable Stickers, Quick Installation Guide, European Union Regulatory Notice, Wi-Fi Antenna, M.2 Plate Screw
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® ALC897 7.1-Channel High Definition Audio
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 4x M.2 - RAID 0, 1
Złącza PCI Express x1:
1
Złącza PCI Express x16:
3
