Uwagi do pamięci RAM: Memory Support DDR5 10000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s, Ryzen™ 9000 Series Processors max. overclocking frequency:, - 1DPC 1R Max speed up to 8400+ MT/s, - 1DPC 2R Max speed up to 8000+ MT/s, Supports AMD POR Speed and JEDEC Speed, Supports Memory Overclocking and AMD EXPO, Supports Dual-Channel mode, Supports Non-ECC, Un-buffered memory, Supports CUDIMM, Clock Driver bypass mode only
Zintegrowany kontroler SATA: Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 3x M.2 - RAID 0, 1, 5
Uwagi do kontrolera SATA: - M.2_1 Source (From CPU) supports up to PCIe 5.0 x4,, supports 2280 devices, - M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 ,, supports 2280 devices, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4,, supports 2280 devices, M.2_1 slot (From CPU):, - Supports up to PCIe 4.0 x4, - Supports single sieded M.2 SSD only, M.2_3 slot (From X870 chipset)(5-in-1 XPANDER Card):, - Supports up to PCIe 4.0 x4, - Supports single sieded M.2 SSD only, Supports RAID 0, and RAID 1 for SATA storage devices, Supports RAID 0, RAID 1 and RAID 5* for M.2 NVMe storage devices, RAID 5 configuration is only supported by Ryzen™ 9000 series processors.
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: 2x USB4 Type-C, HDMI
Uwagi do karty graficznej: Support HDMITM 2.1 with TMDS port, supporting a maximum resolution of, 4K 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed.
Zintegrowana karta dźwiękowa: Realtek® ALC4080 7.1-Channel USB High Performance Audio CODEC
Uwagi do karty dźwiękowej: Supports up to 32-Bit/384 kHz playback on front panel
Złącza PCI Express x16: 1
Uwagi do złącz PCI: PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E1 slot (From CPU):, - Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), - Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor), 1x FP card slot:, - Supports the installation of MSI 5-in-1 XPANDER card only.
Port LAN: 1x 5 Gigabit LAN Realtek® 8126
Maksymalna ilość portów USB 2.0: 2
Maksymalna ilość portów USB 3.x: 9
Maksymalna ilość portów USB 4.0: 2
Porty USB na panelu tylnym: 5x USB 3.1 + 1x USB 3.1 Type-C + 2x USB4 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 + 2x USB 3.0 + 1x USB 3.2 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Wi-Fi 7, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps, Supports Bluetooth 5.4, MLO, 4KQAM, 6GHz band support may depend on every country's regulations and Wi-Fi 7, will be ready in Windows 11 SV3., The Bluetooth version may be updated, please refer to the Wi-Fi chipset, vendor's website for details, Bluetooth 5.4 support schedule depends on MSFT Windows 11 plan.
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU Fan, Combo Fan (Pump_Sys Fan), EZ Conn-header (JAF_2), 2x Front Panel, Chassis Intrusion (JCI), Addressable V2 RGB LED connector, 4x EZ Debug LED, System Fan
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 170 x 170
Opakowanie: BOX
Wyposażenie dodatkowe: European Union Regulatory Notice, Quick Installation Guide, Cable Sticker, EZ Wi-Fi Antenna, 5-in-1 XPANDER Card, 5-in-1 XPANDER USB 5Gbps Cable, USB Drive, 2 x SATA Cables, 1 to 3 EZ Conn-Cable (V2), EZ Front panel cable, 3x M.2 Screws
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Support for Windows 11 64-bit
2x Front Panel, 4x EZ Debug LED, Addressable V2 RGB LED connector, Chassis Intrusion (JCI), Combo Fan (Pump_Sys Fan), CPU Fan, EZ Conn-header (JAF_2), System Fan
Supports up to 32-Bit/384 kHz playback on front panel
Uwagi do karty graficznej:
4K 60Hz, Available only on processors featuring integrated graphics, Graphics specifications may vary depending on the CPU installed., Support HDMITM 2.1 with TMDS port, supporting a maximum resolution of
Uwagi do kontrolera SATA:
- M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 ,, - M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 ,, - M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 ,, - Supports single sieded M.2 SSD only, - Supports up to PCIe 4.0 x4, M.2_1 slot (From CPU):, M.2_3 slot (From X870 chipset)(5-in-1 XPANDER Card):, RAID 5 configuration is only supported by Ryzen™ 9000 series processors., supports 2280 devices, Supports RAID 0, and RAID 1 for SATA storage devices, Supports RAID 0, RAID 1 and RAID 5* for M.2 NVMe storage devices
Uwagi do pamięci RAM:
- 1DPC 1R Max speed up to 8400+ MT/s, - 1DPC 2R Max speed up to 8000+ MT/s, Memory Support DDR5 10000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s, Ryzen 9000 Series Processors max. overclocking frequency:, Supports AMD POR Speed and JEDEC Speed, Supports CUDIMM, Clock Driver bypass mode only, Supports Dual-Channel mode, Supports Memory Overclocking and AMD EXPO, Supports non-ECC, un-buffered memory
Uwagi do procesora:
Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Uwagi do WiFi / BT:
6GHz band support may depend on every country's regulations and Wi-Fi 7 (11953), Bluetooth 5.4 support schedule depends on MSFT Windows 11 plan., Supports Bluetooth 5.4, MLO, 4KQAM, Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps, The Bluetooth version may be updated, please refer to the Wi-Fi chipset, The Wireless module is pre-installed in the M.2 (Key-E) slot, vendor's website for details (5978), Wi-Fi 7, will be ready in Windows 11 SV3.
Uwagi do złącz PCI:
- Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor), - Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors), - Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors), - Supports the installation of MSI 5-in-1 XPANDER card only., 1x FP card slot:, PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU), PCI_E1 slot (From CPU):
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
170 x 170
Wyposażenie dodatkowe:
1 to 3 EZ Conn-Cable (V2), 2x SATA Cables, 3x M.2 Screws, 5-in-1 XPANDER Card, 5-in-1 XPANDER USB 5Gbps Cable, Cable Sticker, European Union Regulatory Notice, EZ Front Panel Cable, EZ Wi-Fi antenna, Quick Installation Guide, USB Drive
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® ALC 4080 7.1-Channel USB High Performance Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 3x M.2 - RAID 0, 1, 5
Złącza PCI Express x16:
1
