Uwagi do pamięci RAM: Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support CUDIMM memory module
Zintegrowany kontroler SATA: Chipset+CPU: 6x SATA III 6Gb/s - RAID 0,1,10,5 + 5x M.2 - RAID 0,1,10,5
Uwagi do kontrolera SATA: CPU:, - 1x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280, PCIe 5.0 x4/x2 SSD support) (M2A_CPU), - 1x M.2 connector (Socket 3, M key, type 22110/2280, PCIe 4.0 x4/x2 SSD support) (M2B_CPU), - 1x M.2 connector (Socket 3, M key, type 22110/2280, PCIe 5.0 x4/x2 SSD support) (M2D_CPU), Chipset:, - 1x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support, PCIe 4.0 x4/x2 SSD support) (M2P_SB), - 1x M.2 connector (Socket 3, M key, type 2280 SATA and, PCIe 4.0 x4/x2 SSD support) (M2M_SB), - 4x SATA 6Gb/s connectors
Uwagi do karty graficznej: - HDMI 1.4 supporting a maximum resolution of 1920x1080@30 Hz, - Support for HDMI 1.4 version, - When a Thunderbolt monitor is installed, the maximum resolution, supported is 5120x2880@60 Hz with 24 bpp (single display output), - When a USB4 USB Type-C monitor is installed, the maximum resolution, supported is 3840x2160@240 Hz (single display output)
Zintegrowana karta dźwiękowa: Realtek® ALC1220 CODEC
Uwagi do karty dźwiękowej: ESS ES9118 DAC chip, Support for DTS:X® Ultra, High Definition Audio, 2/4/5.1-channel
Złącza PCI Express x16: 3
Uwagi do złącz PCI: CPU:, - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 PCIEX1, - The PCIEX16 slot can only support a graphics card or an NVMe SSD, - If only one graphics card is to be installed, be sure to install it in, the PCIEX16 slot, - The PCIEX16 slot shares bandwidth with the M2D_CPU connector, - The PCIEX16 slot operates at up to x8 mode when a device is installed in, the M2D_CPU connector, Chipset:, - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4), - 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
Port LAN: 1x 10 Gigabit LAN Marvell® AQtion AQC113C
Maksymalna ilość portów USB 2.0: 6
Maksymalna ilość portów USB 3.x: 15
Maksymalna ilość portów USB 4.0: 2
Porty USB na panelu tylnym: 2x USB 2.0 + 4x USB 3.0 + 6x USB 3.1 + 2x Thunderbolt 4 (USB4 Type-C)
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Intel Wi-Fi 7 BE200NGW, - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency b, - BLUETOOTH 5.4, - Support for 11be 320MHz wireless standard, - Actual data rate may vary depending on environment and equipment, - Wi-Fi 7 features require Windows 11 SV3 to function properly, - Wi-Fi 7 channels on 6 GHz band availability depends on country's regulati
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: 2x SMA antenna connectors (2T2R), Q-Flash Plus button, Clear CMOS button(s), CPU fan/water cooling pump header, 4x system fan headers, 4x system fan/water cooling pump headers, 4x addressable RGB Gen2 LED strip headers, RGB LED strip header, Gniazdo modułu TPM, Noise detection header, Reset jumper, Clear CMOS jumper, 2x temperature sensor headers
2/4/5.1-channel, ESS ES9118 DAC chip, High Definition Audio, Support for DTS:X® Ultra
Uwagi do karty graficznej:
- HDMI 1.4 supporting a maximum resolution of 1920x1080@30 Hz, - Support for HDMI 1.4 version, - When a Thunderbolt monitor is installed, the maximum resolution, - When a USB4 USB Type-C monitor is installed, the maximum resolution, supported is 3840x2160@240 Hz (single display output), supported is 5120x2880@60 Hz with 24 bpp (single display output)
Uwagi do kontrolera SATA:
- 1 x M.2 connector (Socket 3, M key, type 22110/2280, - 1x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support), - 1x M.2 connector (Socket 3, M key, type 2280 SATA and, - 1x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280, - 4 x SATA 6Gb/s connectors, Chipset:, CPU:, PCIe 4.0 x4/x2 SSD support) (M2B_CPU), PCIe 4.0 x4/x2 SSD support) (M2M_SB), PCIe 4.0 x4/x2 SSD support) (M2P_SB), PCIe 5.0 x4/x2 SSD support) (M2A_CPU), PCIe 5.0 x4/x2 SSD support) (M2D_CPU)
Uwagi do pamięci RAM:
(operate in non-ECC mode), Support CUDIMM memory module, Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
L3 cache varies with CPU
Uwagi do WiFi / BT:
- 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency b, - Actual data rate may vary depending on environment and equipment, - BLUETOOTH 5.4, - Support for 11be 320MHz wireless standard, - Wi-Fi 7 channels on 6 GHz band availability depends on country's regulati, - Wi-Fi 7 features require Windows 11 SV3 to function properly, Intel Wi-Fi 7 BE200NGW
Uwagi do złącz PCI:
- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1), - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 PCIEX1, - 1x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 PCIEX4, - If only one graphics card is to be installed, be sure to install it in, - The PCIEX16 slot can only support a graphics card or an NVMe SSD, - The PCIEX16 slot operates at up to x8 mode when a device is installed in, - The PCIEX16 slot shares bandwidth with the M2D_CPU connector, Chipset:, CPU:, the M2D_CPU connector, the PCIEX16 slot
Wymiary [S x W] (mm):
305 x 244
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® ALC1220 CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 6x SATA III 6Gb/s - RAID 0,1,10,5 + 5x M.2 - RAID 0,1,10,5
Złącza PCI Express x16:
3
