Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2 - RAID 0,1,5,10
Uwagi do kontrolera SATA: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, M key, type 2280 SSDs:, - AMD Ryzen 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs, - AMD Ryzen 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector on the back of the motherboard (M2C_SB), integrated in, the Chipset, supporting Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSDs, 2 x SATA 6Gb/s connectors, RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors., RAID 0 and RAID 1 support for SATA storage devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: USB4 Type-C, HDMI
Uwagi do karty graficznej: Integrated Graphics Processor with AMD Radeon Graphics support+ASMedia, USB4 Controller:, - 1 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video, outputs and a maximum resolution of 3840x2160@240 Hz, Support for DisplayPort 1.4 version and HDR, Integrated Graphics Processor with AMD Radeon Graphics support:, - 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Support native HDMI 2.1 TMDS compatible ports, Graphics specifications may vary depending on CPU support
Zintegrowana karta dźwiękowa: Realtek® ALC 4080 2-Channel High Definition Audio CODEC
Gniazda karty dźwiękowej: 2x Audio Jack
Złącza PCI Express x16: 1
Uwagi do złącz PCI: 1x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD.
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 4
Maksymalna ilość portów USB 3.x: 8
Maksymalna ilość portów USB 4.0: 1
Porty USB na panelu tylnym: 2x USB 2.0 + 2x USB 3.0 + 2x USB 3.1 + 1x USB 3.1 Type-C + 1x USB4 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Realtek® Wi-Fi 7 RTL8922AE, - 802.11a,b,g,n,ac,ax,be, supporting 2.4/5/6 GHz carrier frequency bands, - Support for 11be 160MHz wireless standard, Actual data rate may vary depending on environment and equipment, Wi-Fi 7 features require Windows 11 SV3 to function properly; no W10, supportdriver, Wi-Fi 7 channels on 6 GHz band availability depends on individual country's, regulations
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, CPU fan/water cooling pump header, System fan header, 2x Addressable RGB Gen2 LED strip header, Front panel header, RGB LED strip header, Speaker header, Front Panel Audio header (AAFP), Reset jumper, Clear CMOS jumper, Chassis intrusion header
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 170 x 170
Opakowanie: BOX
Informacje dodatkowe: Bundled Software, - Norton® Internet Security (OEM version), - LAN bandwidth management software, System operacyjny: Support for Windows 11 64-bit
Parametry:
BIOS:
256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset płyty głównej:
AMD X870
Format płyty:
Mini-ITX
Gniazda karty dźwiękowej:
2x Audio Jack
Gniazda karty graficznej:
HDMI, USB4 Type-C
Gniazda USB na płycie głównej:
2x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 Type-C
Gniazdo procesora:
Socket AM5
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Ilość złącz pamięci DDR5:
2
Inne porty i gniazda:
2x Addressable RGB Gen2 LED strip header, Chassis intrusion header, Clear CMOS jumper, CPU fan header, CPU fan/water cooling pump header, Front Panel Audio header (AAFP), Front panel header, Reset jumper, RGB LED strip header, Speaker header, System fan header
Maksymalna ilość portów USB 2.0:
4
Maksymalna ilość portów USB 3.x:
8
Maksymalna ilość portów USB 4.0:
1
Maksymalna wielkość pamięci:
128 GB
Obsługiwane typy procesorów:
AMD Ryzen™
Opakowanie:
BOX
Port Bluetooth:
Bluetooth V5.4
Port LAN:
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Port PS/2:
Brak
Port równoległy (LPT):
Brak
Port szeregowy (COM):
Brak
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax/be
Porty USB na panelu tylnym:
2x USB 2.0 + 2x USB 3.0 + 2x USB 3.1 + 1x USB 3.1 Type-C + 1x USB4 Type-C
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - 1 x USB4 USB Type-C ports, supporting USB4 and DisplayPort video, Graphics specifications may vary depending on CPU support, Integrated Graphics Processor with AMD Radeon™ Graphics support:, Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia, outputs and a maximum resolution of 3840x2160@240 Hz, Support for DisplayPort 1.4 version and HDR, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Support native HDMI 2.1 TMDS compatible ports, USB4® Controller:
Uwagi do kontrolera SATA:
- AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs, 1 x M.2 connector on the back of the motherboard (M2C_SB), integrated in, 1x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, 2 x SATA 6Gb/s connectors, M key, type 2280 SSDs:, RAID 0 and RAID 1 support for SATA storage devices, RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices, RAID 5 is only available on AMD Ryzen™ 9000 Series Processors., the Chipset, supporting Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSDs
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
Support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
Uwagi do WiFi / BT:
- 802.11a,b,g,n,ac,ax,be, supporting 2.4/5/6 GHz carrier frequency bands, - Support for 11be 160MHz wireless standard, Actual data rate may vary depending on environment and equipment, Realtek® Wi-Fi 7 RTL8922AE, regulations, supportdriver, Wi-Fi 7 channels on 6GHz band availability depends on individual country's, Wi-Fi 7 features require Windows 11 SV3 to function properly; no W10
Uwagi do złącz PCI:
- AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, The PCIEX16 slot can only support a graphics card or an NVMe SSD.
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
170 x 170
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® ALC 4080 2-Channel High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2 - RAID 0,1,5,10
Złącza PCI Express x16:
1
