Uwagi do pamięci RAM< b>: Support for ECC Un-buffered DIMM 1Rx8 2Rx8 memory modules, (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8 2Rx8 1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA< b>: Chipset+CPU: 4x SATA III 6Gb s - RAID 0,1,5,10 + 2x M.2
Uwagi do kontrolera SATA< b>: CPU:, - 1 x M.2 connector (Socket 3, M key, type 2280, PCIe 5.0 x4 x2 SSD support)M2A_CPU), Chipset:, - 1 x M.2 connector (Socket 3, M key, type 25110 22110 2580 2280, PCIe 4.0x4 x2 SSD support) (M2Q_SB), - 4 x SATA 6Gb s connectors
Uwagi do karty graficznej< b>: - 1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video, outputs and a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 2.1 version., - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 2.1 version., - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3.
Zintegrowana karta dźwiękowa< b>: Realtek® HD Audio CODEC
Uwagi do karty dźwiękowej< b>: High Definition Audio, 2 4 5.1 7.1-channel
Złącza PCI Express x16< b>: 2
Uwagi do złącz PCI< b>: CPU:, - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, (PCIEX16), - The PCIEX16 slot can only support a graphics card or an NVMe SSD., If only one graphics card is to be installed, be sure to install it in, the PCIEX16 slot., Chipset:, - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
Port LAN< b>: 1x 2,5 Gigabit LAN 100 1000 2500 Mb s (Realtek®)
Maksymalna ilość portów USB 2.0< b>: 9
Maksymalna ilość portów USB 3.x< b>: 6
Maksymalna ilość portów USB 4.0< b>: 1
Porty USB na panelu tylnym< b>: 5x USB 2.0 + 3x USB 3.0 + 1x USB 4
Gniazda USB na płycie głównej< b>: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 Type-C
Port Wi-Fi< b>: IEEE 802.11a b g n ac ax
Port Bluetooth< b>: Bluetooth V5.3
Uwagi do WiFi BT< b>: Intel Wi-Fi 6E AX211 (PCB rev. 1.0 2.0), - WIFI a, b, g, n, ac, ax, supporting 2.4 5 6 GHz carrier frequency bands, - BLUETOOTH 5.3, - Support for 11ax 160MHz wireless standard, Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.1 2.1), - WIFI a, b, g, n, ac, ax, supporting 2.4 5 6 GHz carrier frequency bands, - BLUETOOTH 5.3, - Support for 11ax 160MHz wireless standard
Port PS 2< b>: Brak
Port szeregowy (COM)< b>: Brak
Port równoległy (LPT)< b>: Brak
Inne porty i gniazda< b>: CPU fan header, CPU fan water cooling pump header, System fan header, System fan water cooling pump extension cable header, 3x Addressable RGB Gen2 LED strip headers, RGB LED strip header, Front panel header, Front Panel Audio header (AAFP), Trusted Platform Module header, Q-Flash Plus button, Reset jumper, Clear CMOS jumper, 2x SMA antenna connectors (2T2R), 2x Thunderbolt™ add-in card connectors
2x SMA antenna connectors (2T2R), 2x Thunderbolt™ add-in card connectors, 3x Addressable RGB Gen2 LED strip headers, Clear CMOS jumper, CPU fan header, CPU fan/water cooling pump header, Front Panel Audio header (AAFP), Front panel header, Q-Flash Plus button, Reset jumper, RGB LED strip header, System fan header, System fan/water cooling pump extension cable header, Trusted Platform Module header
- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - 1 x USB4® USB Type-C® port, supporting USB4 and DisplayPort video, outputs and a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 2.1 version., Support for HDMI 2.1 version and HDCP 2.3.
Uwagi do kontrolera SATA:
- 1 x M.2 connector (Socket 3, M key, type 2280, - 1x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280, - 4 x SATA 6Gb/s connectors, Chipset:, CPU:, PCIe 4.0 x4/x2 SSD support) (M2Q_SB), PCIe 5.0 x4/x2 SSD support) (M2A_CPU)
Uwagi do pamięci RAM:
(operate in non-ECC mode), Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
L3 cache varies with CPU
Uwagi do WiFi / BT:
- BLUETOOTH 5.3, - Support for 11ax 160MHz wireless standard, - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Intel Wi-Fi 6E AX211 (PCB rev. 1.0/2.0), Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.1/2.1)
Uwagi do złącz PCI:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, - 1x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 PCIEX4, - The PCIEX16 slot can only support a graphics card or an NVMe SSD., (PCIEX16), Chipset:, CPU:, If only one graphics card is to be installed, be sure to install it in, the PCIEX16 slot.
Wymiary [S x W] (mm):
244 x 244
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® HD Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 2x M.2
Złącza PCI Express x16:
2
