Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, M key, type 2580/2280 SSDs:, - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 4 x SATA 6Gb/s connectors
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, D-Sub
Uwagi do karty graficznej: Integrated Graphics Processor:, - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support for native HDMI 2.1 TMDS compatible ports
Zintegrowana karta dźwiękowa: Realtek® HD Audio CODEC
Uwagi do karty dźwiękowej: Ilość kanałów audio 2/4/5.1/7.1, You can change the functionality of an audio jack using the audio software., To configure 7.1-channel audio, access the audio software for, audio settings
Złącza PCI Express x16: 1
Złącza PCI Express x1: 1
Uwagi do złącz PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, For optimum performance, if only one PCI Express graphics card is to be, installed, be sure to install it in the PCIEX16 slot., - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 8
Maksymalna ilość portów USB 3.x: 4
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej: 4x USB 2.0 + 2x USB 3.0
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Realtek® Wi-Fi 6E RTL8852CE, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Support for 11ax 160MHz wireless standard
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, 2x system fan headers, 2x Addressable LED strip headers, RGB LED strip header, Trusted Platform Module header, Q-Flash Plus button, Clear CMOS button(s)
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 244 x 225
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Bundled Software, - Norton® Internet Security (OEM version), - LAN bandwidth management software, System operacyjny:, - Support for Windows 11 64-bit, - Support for Windows 10 64-bit
Parametry:
BIOS:
256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
2x Addressable LED strip headers, 2x system fan headers, Clear CMOS button(s), CPU fan header, Q-Flash Plus button, RGB LED strip header, Trusted Platform Module header
audio settings, Ilość kanałów audio 2/4/5.1/7.1, To configure 7.1-channel audio, access the audio software for, You can change the functionality of an audio jack using the audio software.
Uwagi do karty graficznej:
- 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Integrated Graphics Processor:, Support for HDMI 2.1 version and HDCP 2.3, Support for native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, 4 x SATA 6Gb/s connectors, M key, type 2580/2280 SSDs:, PCIe 4.0 x4/x2 SSDs
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Realtek® Wi-Fi 6E RTL8852CE, Support for 11ax 160MHz wireless standard, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Uwagi do złącz PCI:
- 1x PCI Express x1 slot, supporting PCIe 3.0 and running at x1, - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, For optimum performance, if only one PCI Express graphics card is to be, installed, be sure to install it in the PCIEX16 slot., PCIe 4.0 x16 mode
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
244 x 225
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® HD Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Złącza PCI Express x1:
1
Złącza PCI Express x16:
1
