Uwagi do pamięci RAM: Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, M key, type 2580 SSDs:, - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector (M2P_CPU), integrated in the CPU, supporting Socket 3,, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs, 4 x SATA 6Gb/s connectors
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, 2x DisplayPort
Uwagi do karty graficznej: Integrated Graphics Processor:, - 2 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support for native HDMI 2.1 TMDS compatible ports
Zintegrowana karta dźwiękowa: Realtek® HD Audio CODEC
Uwagi do karty dźwiękowej: Ilość kanałów audio 2/4/5.1/7.1, You can change the functionality of an audio jack using the audio software., To configure 7.1-channel audio, access the audio software for, audio settings
Złącza PCI Express x16: 1
Złącza PCI Express x1: 1
Uwagi do złącz PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD, 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 6
Maksymalna ilość portów USB 3.x: 7
Porty USB na panelu tylnym: 2x USB 2.0 + 3x USB 3.0 + 1x USB 3.0 Type-C
Gniazda USB na płycie głównej: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Realtek® Wi-Fi 6E RTL8852CE, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Support for 11ax 160MHz wireless standard
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, 2x system fan headers, 2x Addressable LED strip headers, RGB LED strip header, Trusted Platform Module header, Q-Flash Plus button, Reset jumper, Clear CMOS button(s), 2x SMA antenna connectors (2T2R)
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 244 x 174
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Bundled Software, - Norton® Internet Security (OEM version), - LAN bandwidth management software, System operacyjny:, - Support for Windows 11 64-bit, - Support for Windows 10 64-bit
Parametry:
BIOS:
256 Mbit flash AMI UEFI; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
2x Addressable LED strip headers, 2x SMA antenna connectors (2T2R), 2x system fan headers, Clear CMOS button(s), CPU fan header, Q-Flash Plus button, Reset jumper, RGB LED strip header, Trusted Platform Module header
audio settings, Ilość kanałów audio 2/4/5.1/7.1, To configure 7.1-channel audio, access the audio software for, You can change the functionality of an audio jack using the audio software.
Uwagi do karty graficznej:
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - 2 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Integrated Graphics Processor:, Support for DisplayPort 1.4 version, Support for HDMI 2.1 version and HDCP 2.3, Support for native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1 x M.2 connector (M2P_CPU), integrated in the CPU, supporting Socket 3,, 1x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, 4 x SATA 6Gb/s connectors, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs, M key, type 2580 SSDs:, PCIe 4.0 x4/x2 SSDs
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Realtek® Wi-Fi 6E RTL8852CE, Support for 11ax 160MHz wireless standard, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Uwagi do złącz PCI:
- AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1), 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, PCIe 4.0 x16 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
244 x 174
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® HD Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2 - RAID 0, 1, 10
Złącza PCI Express x1:
1
Złącza PCI Express x16:
1
