Uwagi do pamięci RAM: Support up to 192 GB (48 GB single DIMM capacity) of system memory, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme, Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA: M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key,, type 25110/2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 5.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors support PCIe 4.0, x4/x2 SSDs, 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3,, M key, type 25110/2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,, M key, type 25110/2580 PCIe 4.0 x4/x2 SSDs, 4 x SATA 6Gb/s connectors, RAID 0, RAID 1, and RAID 10 support for SATA storage devices, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
Wbudowana karta graficzna: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version and HDR, Graphics specifications may vary depending on CPU support
Zintegrowana karta dźwiękowa: Realtek® 8-Channel High Definition Audio CODEC
Uwagi do złącz PCI: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only, one graphics card is to be installed, be sure to install it in the PCIEX16, Chipset:, - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1, (PCIEX1_1/2)
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 7
Maksymalna ilość portów USB 3.x: 10
Porty USB na panelu tylnym: 3x USB 2.0 + 3x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Uwagi do WiFi / BT: Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.0), WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands, Support for 11ax 160MHz wireless standard
Port PS/2: Brak
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, CPU fan/water cooling pump header, 2x system fan headers, System fan/water cooling pump header, 2x Addressable LED strip headers, 2x RGB (RGBW) LED strip headers, CPU cooler LED strip/RGB LED strip extension cable header, Front panel header, Gniazdo modułu TPM, Reset button, Reset jumper, Clear CMOS jumper, 2x SMA antenna connectors (2T2R), Q-Flash Plus button
2x USB 2.0 (4 porty) + 2x USB 3.0 (4 porty) + 1x USB 3.2 Type-C (1 port)
Gniazdo procesora:
Socket AM5
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin)
Ilość złącz pamięci DDR5:
4
Inne porty i gniazda:
2x Addressable LED strip headers, 2x RGB (RGBW) LED strip headers, 2x SMA antenna connectors (2T2R), 2x system fan headers, Clear CMOS jumper, CPU cooler LED strip/RGB LED strip extension cable header, CPU fan header, CPU fan/water cooling pump header, Front panel header, Gniazdo modułu TPM, Q-Flash Plus button, Reset button, Reset jumper, System fan/water cooling pump header
Maksymalna ilość portów USB 2.0:
7
Maksymalna ilość portów USB 3.x:
10
Maksymalna wielkość pamięci:
192 GB
Obsługiwane typy procesorów:
AMD Ryzen™
Opakowanie:
BOX
Port Bluetooth:
Bluetooth V5.3
Port LAN:
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Port PS/2:
Brak
Port równoległy (LPT):
Brak
Port szeregowy (COM):
1x wewnętrzne gniazdo portu COM
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax
Porty USB na panelu tylnym:
3x USB 2.0 + 3x USB 3.0 + 1x USB 3.1 + 1x USB 3.1 Type-C
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Graphics specifications may vary depending on CPU support, Support for DisplayPort 1.4 version and HDR, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 7000 Series Processors support PCIe 5.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1/Phoenix 2 Processors support PCIe 4.0, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs, 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3,, 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3,, 4 x SATA 6Gb/s connectors, M key, type 25110/2580 PCIe 4.0 x4/x2 SSDs, M key, type 25110/2580 SSDs:, M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key,, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices, type 25110/2580 SSDs:, x4/x2 SSDs
Uwagi do pamięci RAM:
Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support up to 192 GB (48 GB single DIMM capacity) of system memory
Uwagi do procesora:
Support for: AMD Ryzen™ 7000/ Ryzen™ 8000 Series Processors
Uwagi do WiFi / BT:
Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.0), Support for 11ax 160MHz wireless standard, WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
Uwagi do złącz PCI:
- 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, (PCIEX1_1/2), 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, Chipset:, one graphics card is to be installed, be sure to install it in the PCIEX16, The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
305 x 224
Wyposażenie dodatkowe:
LAN bandwidth management software, Norton® Internet Security (OEM version)
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek® 8-Channel High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 3x M.2 - RAID 0, 1, 10
Złącza PCI Express x16:
3
