Uwagi do procesora< b>: AMD Socket AM4, support for: 3rd Generation AMD Ryzen™ processors 3rd, Generation AMD Ryzen™ with Radeon™ Graphics processors, * Please refer "CPU Support List" for more information *, Niektóre procesory mogą wymagać aktualizacji BIOS'u przed ich zamontowaniem
Format płyty< b>: Micro-ATX
BIOS< b>: 1x256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7
Uwagi do pamięci RAM< b>: Support for ECC Un-buffered DIMM 1Rx8 2Rx8 memory modules, Support for non-ECC Un-buffered DIMM 1Rx8 2Rx8 1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Please refer "Memory Support List" for more information
Zintegrowany kontroler SATA< b>: Chipset+CPU: 4x SATA III 6Gb s - RAID 0,1,10 + 2x M.2
Uwagi do kontrolera SATA< b>: 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, M key, type 2242 2260 2280 22110 SSDs:, - 3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4 x2 SSDs, - 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA, and PCIe 3.0 x4 x2 SSDs, 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3,, M key, type 2242 2260 2280 SSDs:, - Supporting SATA and PCIe 3.0 x2 SSDs, 4 x SATA 6Gb s connectors, integrated in the Chipset:, Support for RAID 0, RAID 1, and RAID 10
Wbudowana karta graficzna< b>: Brak lub AMD Radeon R-Series Vega (zależy od procesora)
Gniazda karty graficznej< b>: DVI-D, HDMI
Uwagi do karty graficznej< b>: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz, The DVI-D port does not support D-Sub connection by adapter, 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version, HDCP 2.3, and HDR, Maximum shared memory of 16 GB
Zintegrowana karta dźwiękowa< b>: Realtek® ALC 887 8-Channel High Definition Audio CODEC
Uwagi do złącz PCI< b>: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, - 3rd Generation AMD Ryzen™ processors support PCIe 4.0 x16 mode, - 3rd Generation AMD Ryzen™ with Radeon™ Graphics processors support PCIe, 3.0 x16 mode, For optimum performance, if only one PCI Express graphics card is to be, installed, be sure to install it in the PCIEX16 slot, 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:, - Supporting PCIe 3.0 x4 mode, 1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:, - Supporting PCIe 3.0 x1 mode
Port LAN< b>: 1x Gigabit LAN 100 1000 Mb s (Realtek®)
Maksymalna ilość portów USB 2.0< b>: 6
Maksymalna ilość portów USB 3.x< b>: 6
Porty USB na panelu tylnym< b>: 4x USB 2.0 + 4x USB 3.0
Gniazda USB na płycie głównej< b>: 1x USB 2.0 (2 porty) + 1x USB 3.0 (2 porty)
Port PS 2< b>: Port combo klawiatury myszy PS 2
Port szeregowy (COM)< b>: 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT)< b>: Brak
Inne porty i gniazda< b>: 2x Addressable LED strip headers, 2x RGB (RGBW) LED strip headers, CPU cooler LED strip RGB LED strip extension cable header, Gniazdo modułu TPM, Przycisk Q-Flash Plus
2x Addressable LED strip headers, 2x RGB LED strip headers, 2x system fan headers, Clear CMOS jumper, CPU fan header, Gniazdo modułu TPM, Q-Flash Plus button
- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz, - 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - Support for HDMI 2.1 version, HDCP 2.3, and HDR, - The DVI-D port does not support D-Sub connection by adapter
Uwagi do kontrolera SATA:
- 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3,, - 1x M.2 connector (M2B_SB), integrated in the Chipset, supporting, - 4x SATA 6Gb/s connectors, integrated in the Chipset:, M key, type 2280/22110 SSDs:, Socket 3, M key, type 2280 SSDs:
Uwagi do pamięci RAM:
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Uwagi do procesora:
AMD Ryzen 3000 and Ryzen 3000 G-Series Processors, AMD Ryzen 5000 Series Processors/ AMD Ryzen 4000 G-Series Processors/, AMD Socket AM4, support for: AMD Ryzen 5000 G-Series Processors/
Uwagi do złącz PCI:
- AMD Ryzen 5000 G-Series and 4000 G-Series Processors supports PCIe 3x16, - AMD Ryzen 5000 Series and 3000 Series Processors support PCIe 4x16, - Supporting PCIe 3.0 x1 mode, - Supporting PCIe 3.0 x4 mode, 1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:, 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:, 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
Wbudowana karta graficzna:
Brak lub AMD Radeon R-Series/Vega (zależy od procesora)
Wymiary [S x W] (mm):
244 x 244
Wyposażenie dodatkowe:
LAN bandwidth management software, Norton® Internet Security (OEM version)
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek ALC1220 7.1 Surround Sound High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 2x M.2
Złącza PCI Express x1:
1
Złącza PCI Express x16:
2
