Uwagi do pamięci RAM< b>: Support for non-ECC Un-buffered DIMM 1Rx8 2Rx8 1Rx16 memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA< b>: Chipset+CPU: 4x SATA III 6Gb s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Uwagi do kontrolera SATA< b>: 1x M.2 connector, integrated in the CPU, supporting Socket 3, M key,, type 2580 SSDs:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4 x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4 x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 x2 SSDs, 4 x SATA 6Gb s connectors, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices
Wbudowana karta graficzna< b>: Brak lub AMD Radeon™ Graphics (zależy od procesora)
Gniazda karty graficznej< b>: HDMI, DisplayPort
Uwagi do karty graficznej< b>: 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 1.4 version, 1x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3, Support native HDMI 2.1 TMDS compatible ports, Graphics specifications may vary depending on CPU support, Support for up to 3 displays at the same time
Zintegrowana karta dźwiękowa< b>: Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Uwagi do karty dźwiękowej< b>: You can change the functionality of an audio jack using the, audio software. To configure 7.1-channel audio, access the audio software, for audio settings
Złącza PCI Express x16< b>: 1
Złącza PCI Express x1< b>: 1
Uwagi do złącz PCI< b>: 1x PCI Express x16 slot, integrated in the CPU:, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, The PCIEX16 slot can only support a graphics card or an NVMe SSD, Chipset:, - 1x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Port LAN< b>: 1x 1 Gigabit LAN Realtek®
Maksymalna ilość portów USB 2.0< b>: 8
Maksymalna ilość portów USB 3.x< b>: 4
Porty USB na panelu tylnym< b>: 4x USB 2.0 + 2x USB 3.0
Gniazda USB na płycie głównej< b>: 2x USB 2.0 (4 porty) + 1x USB 3.0 (2 porty)
Port Wi-Fi< b>: Nie
Port Bluetooth< b>: Nie
Port PS 2< b>: Port combo klawiatury myszy PS 2
Port szeregowy (COM)< b>: Brak
Port równoległy (LPT)< b>: Brak
Inne porty i gniazda< b>: CPU fan header, 2x system fan headers, Addressable LED strip headers, RGB LED strip header, Front panel header, Front Panel Audio header (AAFP), Gniazdo modułu TPM, Q-Flash Plus button, Clear CMOS header
2x system fan headers, Addressable LED strip headers, Clear CMOS header, CPU fan header, Front Panel Audio header (AAFP), Front panel header, Gniazdo modułu TPM, Q-Flash Plus button, RGB LED strip header
audio software. To configure 7.1-channel audio, access the audio software, for audio settings, You can change the functionality of an audio jack using the
Uwagi do karty graficznej:
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, 1x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Graphics specifications may vary depending on CPU support, Support for DisplayPort 1.4 version, Support for HDMI 2.1 version and HDCP 2.3, Support for up to 3 displays at the same time, Support native HDMI 2.1 TMDS compatible ports
Uwagi do kontrolera SATA:
- AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs, 1x M.2 connector, integrated in the CPU, supporting Socket 3, M key,, 4 x SATA 6Gb/s connectors, RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, and RAID 10 support for SATA storage devices, type 2580 SSDs:
Uwagi do pamięci RAM:
Extreme Memory Profile (XMP) memory modules, Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- 1x PCI Express x1 slot, supporting PCIe 3.0 and running at x1, - AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode, - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode, - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode, 1x PCI Express x16 slot, integrated in the CPU:, Chipset:, The PCIEX16 slot can only support a graphics card or an NVMe SSD
Wbudowana karta graficzna:
Brak lub AMD Radeon™ Graphics (zależy od procesora)
Wymiary [S x W] (mm):
230 x 225
Wyposażenie dodatkowe:
Norton® Internet Security (OEM version), LAN bandwidth management software
Zawiera baterię / akumulator:
Tak
Zintegrowana karta dźwiękowa:
Realtek ® 7.1 Surround Sound High Definition Audio CODEC
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10 + 1x M.2 - RAID 0, 1, 10
Złącza PCI Express x1:
1
Złącza PCI Express x16:
1
